CN-N-800M Laboratory Biological Microscope

Optical System: lnfinite Optical System
Viewing Head: Compensation Free trinocular Head, lnclined at 300,3600Ratatable,lnterpupilary Distance 48-75mm
Eyepiece: Extra Wide Field Eyepiece WF10X/22
Nosepiece: lnverse Quintuple Nosepiece
Objective: lnfinite plan achromatic objective 4x,10x,40x,100x
Condenser: Swing condenser N.A.0.9/0.25
Focusing: Coaxial Coarse & Fine Focus Adjustment, Fine Division 0.002mm
Stage: Double Layers Mechanical Stage 185x142mm, Moving Range 75x55mm
kohler lllumination: External lllumination, Halongen Lamp 12v30w


Specification

Optical System: lnfinite Optical System

Viewing Head: Compensation Free trinocular Head, lnclined at 300,3600Ratatable,lnterpupilary Distance 48-75mm

Eyepiece: Extra Wide Field Eyepiece WF10X/22

Nosepiece: lnverse Quintuple Nosepiece

Objective: lnfinite plan achromatic objective 4x,10x,40x,100x

Condenser: Swing condenser N.A.0.9/0.25

Focusing: Coaxial Coarse & Fine Focus Adjustment, Fine Division 0.002mm

Stage: Double Layers Mechanical Stage 185x142mm, Moving Range 75x55mm

kohler lllumination: External lllumination, Halongen Lamp 12v30w



Optional

Objective: Lnfinite plan achromatic objective 20x

Photo attachment

Video adapter: C Mount 1x or C Monut 0.5x

Polarization attachment

Turret phase contrast kit

Dark field attacment

Epi-fluorescent attachment

Temperature controlled stage
