CN-5S Portable Slit Lamp Microscope

Feature
Binocular crossed stereomicroscope provides sharp observation.
High illumination white LED fully charged can be use for 5 or 6 hours
Compact and one hand operational, portable for carrying with.
Net weight: 750g.
Equipped with all functions of a desktop slit lamp
Fully charged can be used for 5-6 hours
4 light spots is option.

Specification

Microscope Type

Converging microscope

Objective

Magnification

1X

Eyepiece Magnifications

10X,16X

Diopter compensation

±7D

Pupil Distance

48mm 70mm

Working Distance

80mm

Slit Width

010mm continuously adjustable

Diameter of Light Spot

10mm

Filter

Heat –absorption, Grey, Redfree, Cobalt Blue

Slit Angle

Horizontal ±30°

Light Source

LED

Power

7.2V 750Ah Li Battery, Rechargeable

Working Time

5-6 hours

Net Weight

750g

Packing Volume

390mm * 180mm *220mm

Gross Weight

2500g
